Variable Speed, Mitering 5″ X 6″ Horizontal Bandsaw, 0.5HP 115V
This Jet variable speed, mitering band saw packs the features in a small package. The exclusive 5 x 6 portable variable speed mitering Bandsaw includes a newly designed motor with a 3-step gear transmission for unprecedented torque output. The versatile swiveling head allows precision cuts without the hassle of moving the material.
Features
Heavy duty casted head for years of sawing
New DC motor with 3-step gear transmission increases torque output
Ball bearing supported blade wheel
CSA/US: following strict guidelines and electrical requirements, this Jet saw is CSA/US certified
Blade is fully guarded
Automatic shut-off after cut
Head swivels for a maximum cut at 45° and 65°
Variable speed gives you the ability to cut various materials
Hardened ferrous 82-130 SFPM
Non-ferrous, plastic, wood 180-230 SFPM
Quick speed changes with the turn of a dial, no more belt changes
Fully adjustable ball bearing blade guides
Front legs feature leveling pads
Wheels come standard for ease of movement around your shop
Specifications
Acme Tools Brand Name
JET
Acme Tools Part Number
414558
Amperage (A)
15
Assembled Weight (lbs)
176.0
Band Saw Type
Bench
California Proposition 65 Warning Required
Yes
Color / Finish
black
Cordless / Corded
Corded
Country of Origin
Taiwan
CSA Certified
Pending
Dust Port
No
ETL Listed
Pending
Horsepower (hp)
0.5
Internal Supplier Part #
414558
Internet Product Code (IPC)
D92B6A27C3A
Manufacturer Warranty
2 year warranty
Material
Steel
Maximum Blade Length (In)
38.58
Maximum Blade Width (In)
20.47
Maximum RPM
230
Minimum Blade Width (in)
0.5
Package Depth
18
Package Height
41
Package Weight
176
Package Weight (lbs)
176
Speeds
230
Table Length (in)
6
Table Material
Steel
Table Width (in)
20.47
UL Listed
Pending
Variable Speed
Yes
Voltage
230 Volts
