Diamond Products CC150XL-EE First Cut Concrete Saw True Early Entry Series 6″ Honda GX160 Engine 4.8HP
Diamond Products CC150XL-EE First Cut Concrete Saw True Early Entry Series Honda GX160 Engine 4.8HP. Reliable skid plate system for green concrete.Maximum cutting depth of 1-3/16”. Heavy duty design but light weight enough for two people to lift. Cyclone air filter for increased air flow. Up-cut design to keep debris from going back in the cut. Blade raise/lower mechanical mechanism with spring loaded release. Single ribbed drive belt.
Features
Maximum cutting depth of 1-3/16”
Reliable skid plate system for green concrete
Heavy duty design but light weight enough for two people to lift
Cyclone air filter for increased air flow
Up-cut design to keep debris from going back in the cut
Blade raise/lower mechanical mechanism with spring loaded release
Single ribbed drive belt
Blade shaft RPM: 2,600
Blade shaft diameter: 1-1/4”
Handle bars: Adjustable
Depth indicator: Standard
Specifications
Acme Tools Brand Name
DIAMOND PRODUCTS
Acme Tools Part Number
32739
Arbor Size
1 in
Assembled Weight (lbs)
300
Blade Size (in)
6.5
California Proposition 65 Warning Required
Yes
CARB Compliant
No
Color / Finish
White
Country of Origin
United States
Engine Cycles
4 Cycle
Horsepower (hp)
4.8
Internal Supplier Part #
32739
Internet Product Code (IPC)
0B2D0C4818E
Manufacturer Warranty
1 year
Maximum Cutting Depth (in)
1.5
Maximum RPM (No Load)
4020
Net Tool Weight (lbs)
100
Package Depth
16.5
Package Height
21.8
Package Weight
300
Size
Blade size 6.5 in
Start Type
Pull
